CG200 Series


http://www.ssvvalve.com//wp-content/uploads/2017/12/CG200-With-Dunlap3.png

CG200 with DunlapⅢ Trim (Noise Abatement Trim)

Control Valve -- CG200 Series

SSV CG200 Series valve is your solution for all general applications with high process temperatures, featuring a balanced or unbalanced plug design and cage-guided trim. Available in globe or angle body, these valves can provide up to Class V or VI shutoff.
CONFIGURATIONS :
Single-port, globe-style,Angle-Style control valve with cage guiding, balanced or unbalanced valve plug
CRITICAL SERVICE :
Noise Abatement, Cavitation, Steam Condition, Erosive, Low Flow, Corrosive, General Service, Outgassing, Flashing

SPECIFICATIONS

SIZE RANGE

1.0" ~ 8.0"

RATING PRESSURE

ASME 150 ~ 600 Class

END CONNECTIONS

Flanged, Butt Weld, RTJ, Threaded, Socket Weld

FLOW CHARACTERISTICS

Equal percentage, Linear, Special Characterization, Quick Opening

SHUTOFF CLASS

Class IV , Class V , Class VI  (ANSI / FCI70-2 and IEC60534-4 )
