SG200 Series


Highly reliable flow control technologies help you regulate and isolate your processes with certainty.

http://www.ssvvalve.com//wp-content/uploads/2017/12/4.0-Inch-SG200-with-PSR-Act.png

4 Inch SG200 Valve With SSV PSR Actuator

Control Valve -- SG200 Series

SSV SG200 Series control valves are used for throttling or on-off control of a wide variety of liquids and gases. The single-port, globe-style body design offers quick-change trim and a post-guided,unbalanced valve plug. The SG200 valve is used in chemical or hydrocarbon processing applications or wherever control of non-lubricating, viscous, or other hard-to-handle fluids is required.
CONFIGURATIONS :
Single-port, globe-style control valve , post guiding, unbalanced valve plug
CRITICAL SERVICE :
Noise Abatement, Cavitation, Steam Condition, Erosive, Low Flow, Corrosive, General Service, Outgassing, Flashing

SPECIFICATIONS

SIZE RANGE
1.0" ~ 4.0"
RATING PRESSURE
ASME 150 ~ 600 Class
END CONNECTIONS
Flanged, Butt Weld, RTJ, Threaded, Socket Weld
FLOW CHARACTERISTICS
Equal percentage, Linear, Special Characterization, Quick Opening
SHUTOFF CLASS
Class IV , Class V , Class VI  ( ANSI / FCI70-2 and IEC60534-4)
